RM-1730S _ 17.3 inch Pull-out rackmount monitor

Short Description:

As a 1RU pull-out pro rackmount monitor, features 17.3″ 1920×1080 FullHD IPS screen with fine picture quality and good color reduction. It’s interfaces support SDI and HDMI signals inputs and loop outputs; And also supports SDI/HDMI signal cross conversion. For the advanced camera auxiliary functions, such like waveform, vector scope and others, all are under professional equipment testing and correction, parameters accurate, and comply with industry standards.


  • Model: RM-1730S
  • Physical resolution: 1920x1080
  • Interface: SDI, HDMI, DVI, LAN
  • Feature: SDI & HDMI cross conversion
  • Product Detail

    Specifications

    Accessories

    RM1730S_ (1)

    Excellent Display

    It features 17.3″ 16:9 IPS panel with 1920×1080 full HD resolution, 700:1 high contrast, 178° wide viewing angles,

    300cd/m² high brightness,which offers outstanding viewing experience.

    Advanced Functions

    Lilliput creatively integrated column (YRGB peak), time code, waveform, vector scope & audio level meter into

    field monitor. These assist users to accurately monitor when shooting, making and playing movies/videos.





    RM1730S_ (2)

    Durable & Space-saving

    Metal housing with pull-out drawer type design, which provides perfect protection for a 17.3 inch monitor from shock and drop. It’s also convenient for

    portable outdoor, or applied in rack mount because of amazing space-saving design. Power will be off automatically when screen down and pushed in.

    Cross Conversion

    The HDMI output connector can actively transmit an HDMI input signal or output an HDMI signal that has been converted from an SDI signal.In short,

    signal transmits from SDI input to HDMI output and from HDMI input to SDI output.









    RM1730S_ (3)

    Intelligent SDI Monitoring

    It has a various of mounting methods for broadcast, on-site monitoring and live broadcast van, etc. A 1U rack design for a customized monitoring

    solution, which not only can save the space of rack greatly with a 17.3 inch monitor, but also viewed from different angles when monitoring.





    RM1730S_ (4) RM1730S_ (5)


  • Previous:
  • Next:

  • Display
    Size 17.3”
    Resolution 1920×1080
    Brightness 330cd/m²
    Aspect ratio 16:9
    Contrast 700:1
    Viewing Angle 178°/178°(H/V)
    Video Input
    SDI 1×3G
    HDMI 1×HDMI 1.4
    DVI 1
    LAN 1
    Video Loop Output (SDI / HDMI cross conversion)
    SDI 1×3G
    HDMI 1×HDMI 1.4
    Supported In / Out Formats
    SDI 720p 50/60, 1080i 50/60, 1080pSF 24/25/30, 1080p 24/25/30/50/60
    HDMI 720p 50/60, 1080i 50/60, 1080p 24/25/30/50/60
    Audio In/Out (48kHz PCM Audio)
    SDI 12ch 48kHz 24-bit
    HDMI 2ch 24-bit
    Ear Jack 3.5mm
    Built-in Speakers 2
    Power
    Operating power ≤32W
    DC In DC 10-18V
    Environment
    Operating Temperature -20℃~60℃
    Storage Temperature -30℃~70℃
    Other
    Dimension(LWD) 482.5×44×507.5mm
    Weight 8.6kg (with case)

    1730 accessories
