7 inch HDMI Camera-top Monitor

Short Description:

339 is a portable camera-top monitor specifically for handheld stabilizer and micro-film production, which features 360g weight only, 7″ 1280*800 native resolution screen with fine picture quality and good color reduction. For the advanced camera auxiliary functions, such like peaking filter, false color and others, all are under professional equipment testing and correction, parameters accurate, and comply with industry standards.

Model: 339

Resolution: 1280*800

Brightness: 400cd/m2

Input: HDMI , AV

Send email to us Download as PDF User guide

Product Detail

Specifications

Accessories

Product Tags

Camera Auxiliary Functions:

Camera Mode
Center Marker
Pixel-to-Pixel
Safety Marker
Aspect Ratio
Check Field
Color Bar

Previous: 7 inch resistive touch monitor

Next: 7inch Wireless AV Monitor

Display
Size	7″ IPS, LED backlit
Resolution	1280×800
Brightness	400cd/㎡
Aspect ratio	16:9
Contrast	800:1
Viewing Angle	178°/178°(H/V)
Input
AV	1
HDMI	1
Output
AV	1
AUDIO
Speaker	1
Earphone	1
HDMI FORMAT
Full HD	1080p(60/59.94/50/30/29.97/25/24/23.98/23.976/24sF)
HD	1080i(60/59.94/50), 1035i(60/59.94) 720p(60/59.94/50/30/29.97/25)
SD	576p(50), 576i (50) 480p (60/59.94), 486i (60/59.94)
Power
Current	580mA
Input Voltage	DC 7-24V
Battery	Built-in 2600mAh battery
Battery Plate (optiional))	V-mount / Anton Bauer mount / F970 / QM91D / DU21 / LP-E6
Power Consumption	≤7W
Environment
Operating Temperature	-20℃~60℃
Storage Temperature	-30℃~70℃
Other
Dimension(LWD)	225×155×23mm
Weight	535g
